The Yaesu FC-40 antenna tuner is designed for the FT-857D, FT-891, FT-897D and FT-991(A). It uses of the control circuitry built into the FT-857/891/897, which allows the operator to control and monitor automatic operation of the FC-40 mounted near the antenna feed point. For demanding applications, the FC-40 uses specially selected thermally stable components and is housed in a waterproof casing to reliably withstand severe climatic extremes. The FC-40 matches a wide variety of antennas to within a 2:1 SWR on any amateur band (160 through 6 meters) in less than 30 seconds. Transmitter power required for matching can be as little as 4 to 60 watts, and matching settings are automatically stored in memory for instant recall when the same frequency range is reselected later. Comes with plate and U bolts plus 4,9 m control cable and 4,9 m coaxial cable.
Specifications
| Frequency range | : | 1.8 to 54 MHz Amateur Bands (with 20+ meter end fed wire) |
| Frequency range | : | 7 to 54 MHz Amateur Bands (with 2.5 meter mobile whip) |
| Max. power | : | 100 W PEP (3 minutes maximum continuous TX) |
| Memories | : | 200 |
| Tuning time | : | 1 to 8 seconds |
| Antenna matching impedance | : | 16,5 to 150 Ohms (SWR less than 3) |
| Tuning power | : | 4 to 60 W |
| Power Supply | : | 13.8 VDC (derived from the transceiver) |
| Dimensions | : | W 175 x H 236 x D 53 mm |
| Weight | : | 1,2 kg |
Maße und Gewicht sind inklusive Verpackung
